技術參數
輸入電壓:AC110-225V/50-60Hz
功率:100W
光源:采用(6*81)總計486顆RGB高亮度燈珠和10W光宏芯片檸檬黃色燈珠
壽命:6-8萬小時 顏色:1670萬種顏色變化
LED 角度:15度
控制:可通過TTL控制器聯動智能中控或DMX512控臺進行控制
可脫機、DVI、ARTNET、DMX512控制方式輸出
尺寸:400*600*205mm
產品特點
1. 像素?zé)舨捎猛哥R外罩,發光均勻柔和
2. 溫度保護,安全可靠
3. 獨有光學系統設計,均勻的色斑效果,不刺眼。
4. 超高頻(64KHz)調光技術,絕無抖動閃
5. 信號連接通過RJ45網口端子輸入
6. 兼容任意一款LED燈帶幻彩控制器,可編程麥爵仕效果
Technical parameter
Input voltage: AC110-225V/50-60Hz
Power: 100W
Light source: Using (6*81) a total of 486 RGB high-brightness beads and 10W optical macro chip lemon yellow lamp beads
Life: 60,000-80,000 hours Color: 16.7 million color variations
LED Angle: 15 degrees
Control: It can be controlled by TTL controller or DMX512 controller
Off-line, DVI, ARTNET, DMX512 control mode output
Size: 400*600*205mm
Product characteristics
1. The pixel lamp uses the lens cover, and the light is uniform and soft
2. Temperature protection, safe and reliable
3. Unique optical system design, uniform stain effect, not dazzling.
4. Ultra high frequency (64KHz) dimming technology, no jitter flash
5. Enter the signal connection through the RJ45 network port terminal
6. Compatible with any type of LED light with magic controller, programmable Mycles effect
